So this motor is used in applications like lifts pumps mills where we require high starting torquegenerally induction motor provides low starting torque as compared to dc series motors but this disadvantages of the induction motor can be overcome by slip ring induction motor. The motor which employing the wound rotor is known as a slip ring induction motor or phase wound motor.
Starting Of Slip Ring Induction Motor Explained In An Easy
Slip ring motor starter diagram pdf. Higher is the inertia higher has to be the accelerating torque otherwise the start will be very long and the motor can be damaged by the heating. It also requires meticulous and periodic maintenance of the brushes brush gear slip rings external rotor resistances etc. A slip ring motor is expensive as are its controls compared to a squirrel cage motor. The slip ring induction motor has two distinctly separate parts one is the stator and other is the rotor. A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. The stator circuit is rated as same in the squirrel cage motor but the rotor is rated in frame voltage or short circuit current.
For slip ring induction motor by providing external resistance in rotor circuit we can also limit starting current. It consists laminated cylindrical core which has a semi closed slot at the outer periphery and carries three phase insulated winding. It can improve mechanical performance simplify system operation and eliminate damage prone wires dangling from movable joints. As discussed earlier a slip ring induction motor is an asynchronous motor as the rotor never runs in synchronous speed with the stator poles. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. However we selected the rotor.
There are different methods of starting of 3 phase slip ring induction motor. Why using a starter for slip ring motors. In order to start a slip ring motor the accelerating torque has to be sufficiently higher than the resisting torque. If the motor is started directly. Three phase induction motor provided with the different starter like star delta starter autotransformer starter and dol starter etc. The frame voltage is the open circuit voltage when the rotor is not rotating and gives the measure of turns.
Slip ring induction motor application slip ring induction motor provides high starting torque. Learn more about the construction and operation of a slip ring induction motor. Three phase slip ring rotor starter control diagram control diagram. Definition of slip ring motor. Three phase motor control installation wiring diagrams. The construction of a stator is the same for both the squirrel cage and slip ring induction motor.
Check more diagrams here. The aim behind the development of the project is to limit the current at starting of motor and to develop the high starting torque. A slip ring motor also requires a larger space for the motor and its. A squirrel cage motor is thus preferred to a slip ring motor.
