Ive tried bringing that lead back to just s1 and then to both s1 and s2. The zwave stuff works fine.
Nano Switch Important Switch Electromagnetic Interference
Aeotec nano dimmer wiring diagram. Then i connect a lead from the other side of the switch back to s1 and s2. Lighting engine auto detects whether your light switches have a neutral wire or not then automatically adjusts it settings. Nano switch is a part of aeotecs gen5 range and is engineered upon the latest version of z wave z wave plus. Things im pretty sure of neutral slot gets a neutral wire to the breaker line slot gets a line wire from the breaker in gets a line wire from the breaker. In this case we keep the standard toggle switches connecting l1 to the modules s1 input with the l2 wire connected to the modules com output. Standard 2 way lighting circuit using the aeotec nano dimmer with toggle switches.
Hi there i just bought an aeotec nano switch and im having trouble getting the toggle switch to work. Since the s1 port and s2 port can be used to control the load separately you can choose to connect the spdt switches to the s1 or s2. Nano switch comes in an edition infused with aeotecs super accurate energy metering technology which records electricity use with 99 accuracy. To retain your existing standard toggle switches we can simple install the module as shown in figure 2. So what i dont understand is what i need to do to get the nano switch working in this circuit. The diagram indicates that i should take a lead from the line live to one side of the switch.
Nano dimmer isnt just better at lighting compatibility its better at wiring compatibility too. Whether your lights are installed in a 2 wire or 3 wire system nano dimmer is compatible. Aeotec nano switch 3 way diagram. The below diagram will show you that the nano dimmer uses the spdt single pole double throw switches as the external manual switch. 10 23 wiring diagram of spdt as the external manual switch.
