The essence of the wiring configuration is for one hot feed wire entering the switch box to be split so that it feeds both switches which in turn feed hot wires in cables that lead out to two separate light fixtures. It is not uncommon for a circuit to be configured so that two wall switches in a single double gang box control two different light fixtures.
A Two Gang Schematic Wiring Wiring Diagram
Wiring a two gang light switch. Wiring a switch loop. The black wire from each light is connected to one of the switches and the source neutral and ground are shared by the two light fixtures. Two way means that the switch has two positions on and off and two gang means that two switches are packaged together. Learn how to wire a switch. When the electrical source originates at a light fixture and is controlled from a remote location a switch loop is used. This circuit is wired with a 2.
Terry peterman the internet electrician introduces the first of a series of instructional videos covering how to wire a two gang switch from rough in to wiring. Wiring a 3 way light switch. Also included are wiring arrangements for multiple light fixtures controlled by one switch two switches on one box and a split receptacle controlled by two switches. 3 way light switch wiring 2 wire system this switch arrangement is basically two two way switches on a single face plate. A two gang two way light switch sounds complicated but its actually the very common two switch light fixture youre probably used to seeing in your home. With a pair of 3 way switches either can make or break the connection that completes the circuit to the light.
Wiring a 3 way light switch is certainly more complicated than that of the more common single pole switch but you can figure it out if you follow our 3 way switch wiring diagram. Some brands of light switch may have slightly different labeling on the terminals such as c l1 l2 or even l1 l2 and l3. Wiring a switch and outlet in the same box in this diagram a light switch and receptacle are wired in the same box.
