Physical switches wired to outputs devices such as motor contactor and relays. With the motor running contacts are open.
Motor Starter Wiring Diagram Of Phase 1 Wiring Diagram Images
Start stop jog motor control diagram. L3 t3 t three wires three wjfes lead from the plot devtce to thestarter. The jog circuit can be used in almost any control circuit because it relies on momentary energizing and de energizing of the pilot device. Looking at a stop start jog circuit in the plc will help us in understanding the differences in hard wiring the circuit and programming. Jogging or inching is defined as the quickly repeated closure of a circuit to start a motor from rest for the purpose of accomplishing small movements of rotating machine. It uses three contactors an overload relay one auxiliary contact block a normally open start pushbutton a normally closed stop pushbutton an on delay timer of 0 20 seconds and a power supply with a fuse. In a jog motor control a dual push button with one normally motor control open and one normally close contacts is inserted in between the normal stop and start push button of the across the line magnetic starter.
To jog the motor simply hold down the stop button and jog the circuit by pressing the start button. Undervoltage protection and three wrre control should brmg to mrnd a start stop push button staton whrch the most common means of provrdrng this type control. C i m nc. Pilot light l2 4 2 3 pilot light start stop bulletin 1495 normally closed auxiliary contacts are required. When you press the start button and the stop button is not pressed the 24vdc relay energizes and it pulls in the r1 contactor that feeds three phase power to the motor. Start stop and jog.
Here is what it looks like hard wired. Lets start with the basic stop stop circuit. Motor starter with start stop and jog. For push button control stations 7 start stop control wiring diagrams single station with motor stopped pilot light l1 start l2 i 1 stop 2 oi 3 n wol. Wye delta open transition 3 phase motors. The most common use of 3 wire control is a startstop control.
This video builds on the standard 3 wire circuit by incorporating multiple stopstart stations. Ladder diagram basics 3c 3 wire control duration. See image below for an example of 3 wire control being used to pull in a contactor to start a 3 phase motor. The following diagram is shown for 3 phase motor control of a delta star connection. T w 6. The start and stop operation of the jog motor control is the same as the start and stop operation of the across line magnetic starter.
Control circuit until the start button is pressed once again. This circuit is basically a start stop push button control circuit that has been reconnected so that the start button is in parallel with both the stop button and holding contact. Motor control jog circuit diagram.
